High Pressure CNG Hose Pipe 5000psi for Dispensers in Transfer Vehicles

Tempat asal:

Cina

Nama merek:

PASSION

Sertifikasi:

Nomor model:

CNG

Hubungi kami

Permintaan Penawaran

Rincian Produk

Ban dalam:

Bahan termoplastik konduktif

Bantuan:

Serat yang dikepang

Tabung luar:

Polyurethan (PU)

PENGENAL:

1/4 ", 5/16", 3/8 ", 1/2", 3/4 ", 1"

Radius tikungan min:

51 mm - 254 mm

Panjang:

0,2 meter, 0,3 meter, 2,8 meter atau sebagai permintaan Anda

diameter luar:

14mm, 16.5mm, 22.9mm, 30.2mm, 40.4mm

Kemasan:

Dikemas dalam karton

Aplikasi:

Dispenser CNG

MOQ:

1000 meter

Waktu Pimpin:

biasanya 30 hari

Pabrikan:

Paishun

Merek:

Selang Passionco

Tekanan Kerja:

5000 psi

Tekanan Ledakan:

14000 psi

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order

1000 meter

Kemasan rincian

Dikemas dengan baik oleh karton berkualitas tinggi atau tali pengikat

Waktu pengiriman

30 hari

Syarat-syarat pembayaran

T/T

Menyediakan kemampuan

10000 buah/bulan

Produk-produk terkait

video

Selang gas alam kompresi ringan 5000 PSI untuk pompa bensin

Dapatkan Harga Terbaik

Selang CNG dengan Penguat Anyaman Kawat untuk Pengiriman Gas Alam Bertekanan Tinggi

Dapatkan Harga Terbaik

video

Tekan Tinggi Kawat Perekat Perkuat Lapisan CNG Selang Untuk Distribusi Gas Alam Dikompresi

Dapatkan Harga Terbaik

Tekan Tinggi Kawat Perekat Perkuat Lapisan CNG Selang Untuk Distribusi Gas Alam Dikompresi

Dapatkan Harga Terbaik

Hubungi kami

Hubungi sekarang

Deskripsi Produk

Electrically Conductive Compressed Gas CNG Transfer Hose 350 Bar

CNG hose incoporated with steel wire is a general hose, what about the hose embedded with aramid fibers?

Comparing with the general type, the CNG hose with aramid fibers is more flexible, more easy to handle, high pressure is guaranteed.

Without steel wire, the hose can still keep anti-static, because we use a " conductive " material to produce the inner tube. It is safe when being used in gas stations.

High pressure hose suitable for CNG refueling applications featuring conductive inner tube to dissipate static electric build up.
Extra tough cover for abrasion water and micro biological resistance.
Non metallic lightweight design for easy handling and manipulation.
Rugged construction to give kink - crush - twist and pull resistance.

In addition to taking the lead in development and mass production of polyure-thane reinforced
hose series (widely used in power steering systems of various buses and vehicles). Our company
studied and developed CNG special hose series relying on our own technical force in 2006. It is
being widely used in the connection pipeline system of loading and unloading between CNG
cylinder cars and pressure reduction station or parent stations.

The product is easy to install and convenient to use. Special CNG hose assembly includes
different coupling means: ball valve, quick coupling and flange, so it is convenient to adjust the
distance of loading and unloading.

The product has strong pressure adaptability. Range of application: 1.0MPa-35Mpa, can meet the
needs of different customers.

Specifications	I.D. (inch)	O.D. (mm)	Service Pressure (psi)	Min Bend Radius (mm)
CNGG-6	1/4"	14.0	5000	51
CNGG-10	3/8"	16.5	5000	76
CNGG-13	1/2"	12.5	5000	102
CNGG-19	3/4"	19	5000	191
CNGG-25	1"	25	5000	254

High Pressure CNG Hose Pipe 5000psi for Dispensers in Transfer Vehicles 0

High Pressure CNG Hose Pipe 5000psi for Dispensers in Transfer Vehicles 1

High Pressure CNG Hose Pipe 5000psi for Dispensers in Transfer Vehicles 2

Application:
